Dettagli del prodotto
Place of Origin: China
Marca: E-link
Certificazione: CE
Model Number: LNK-CWDM-SFP3G
Documento: E-link LNK-CWDM-SFP3G-XX40 ....0.pdf
Termini di pagamento e di spedizione
Minimum Order Quantity: 1pcs
Prezzo: Negoziabile
Packaging Details: Industrial PoE Switch Standard Carton Packaging
Delivery Time: 7-10 working days
Payment Terms: L/C,T/T,Western Union,MoneyGram,PayPal
Supply Ability: 100000PCS/Month
Dimensions (LxWxH): |
80 x 40 x 20 (mm) |
Operating Temperature: |
0°C to 70°C (32°F to 158°F) |
Max. Distance: |
40 km |
Weight: |
0.025Kg |
Part Number: |
LNK-CWDM-SFP3G-XX40 |
Dimensions (LxWxH): |
80 x 40 x 20 (mm) |
Operating Temperature: |
0°C to 70°C (32°F to 158°F) |
Max. Distance: |
40 km |
Weight: |
0.025Kg |
Part Number: |
LNK-CWDM-SFP3G-XX40 |
Vantaggi del prodotto
► Caratteristiche compatibili con SMPTE 297-2006
► Velocità da 50 Mbps a 2,97 Gbps
► Distanza fino a 40 km per 3G-SDI
► Supporta schemi patologici video per SD-SDI, HD-SDI e 3G-SDI
► Trasmettitore DFB CWDM a 18 lunghezze d'onda
► Ingombro SFP a innesto a caldo
► Conforme a SFP MSA
► Funzioni di diagnostica digitale disponibili tramite l'interfaccia I2C
► Alimentazione singola +3,3 V
► Basso consumo energetico
► Temperatura di esercizio: da 0 a +70°C
► Conforme a Ohs e senza piombo
Indici tecnici
Parte numero |
LNK-CWDM-SFP3G-XX40 |
Fattore di forma |
Ricetrasmettitore SFP video |
Data Rate |
3 Gb/s |
Wavelength |
1270~1610nm |
Fiber Type |
SMF |
Distanza massima |
40 km |
Componenti ottici |
DFB/PIN |
Potenza del trasmettitore |
-2 ~3 dBm |
Rapporto di estinzione |
>6 dB |
Sensibilità del ricevitore |
< -20 dBm |
Sovraccarico del ricevitore |
>-3 dBm |
Connettore |
Duplex LC |
Diagnostica digitale (DDM) |
Supporto come predefinito |
Peso |
0,025 kg |
Temperatura di esercizio |
da 0°C a 70°C (da 32°F a 158°F) |
Panoramica
E-link LNK-CWDM-SFP3G-XX40 è un modulo ricetrasmettitore ottico 3G-SDI CWDM ad alte prestazioni ed economicamente vantaggioso per applicazioni di trasmissione video a lungo raggio su fibra monomodale (SMF). Fornisce velocità dati da 50 Mbps a 2,97 Gbps ed è specificamente progettato per prestazioni robuste in presenza di schemi patologici SDI per velocità seriali SMPTE 259M, SMPTE 344M, SMPTE 292M e SMPTE 424M.
Applicazione
Informazioni per l'ordine
Modello |
Descrizione |
LNK-CWDM-SFP3G-2740 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1270 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-2940 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1290 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-3140 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1310 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-3340 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1330 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-3540 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1350 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-3740 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1370 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-3940 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1390 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-4140 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1410 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-4340 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1430 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-4540 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1450 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-4740 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1470 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-4940 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1490 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-5140 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1510 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-5340 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1530 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-5540 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1550 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-5740 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1570 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-5940 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1590 nm, 40 km, LC, DDMI, MSA |
LNK-CWDM-SFP3G-6140 |
Ricetrasmettitore ottico video SDI CWDM da 3 Gb/s SFP, 1610 nm, 40 km, LC, DDMI, MSA |
